MaVIS-ARM (Mass and Volume Information System)
The Intelligent Cargo Scale is one of the most advanced multifunctional weighing electronics in the world.
Accuracy
Features
- Fully automated belt weigher electronics
- Programmable auto zero tracking
- 4 isolated analogue input/output slots (max6)
- 5 isolated digital input/output slots (max8)
- Standard outputs for rate, total and alarm
- RS232/RS485 duplex serial communications (modbus compatible)
- IP66 standard enclosure: powder coated, mild steel, viewing window, wiring direct to circuit board
- Bin scale controller functions
- 110/240 Vac power supply
- Up to 1000 cable metres to Load Cell and Tachometer
- Colour graphical touch screen user interface
- Designed and Built in Australia
Model MaVIS-ICS-ARM
The Intelligent Cargo Scale is one of the most advanced multifunctional weighing electronics in the world. It has the following capabilities and configurations.
- 1 or 2 belt weighers or
- 1 or 2 bins scales, or
- 1 Belt weigher and 1 bin scale
plus
- 1 or 2 flow controllers
- High reliability dual in-line belt weigher
- Loss in weight systems
- Trade Certified Applications
- Integrated Laser Scanner for Bulk Density Measurement
- Communications protocols
Options
- Laser scanner volume and density
- 316 stainless steel flat or sloping roof
- IP66 enclosures
- 316 stainless steel DIP enclosure
- Wiring via DIN rail mount terminals
- Intrinsic Safety (IS) Barriers
- DeviceNet interface or any other popular scada interface
- Event logging/Audit trail (trade certification approved) - span, alarm, zero and data changed events logged
- 24 Vdc power supply
- Uninterruptible power supply
- TCP/IP network access
- Printer Output
- Custom software and control functions
- Up to 6 isolated analogue I/O
- Up to 8 isolated digital I/O
CST Tachometer Products
BTS - Basic Tachometer System
- Economical but very reliable
- Tail or Bend Pulley Mount
- Easily Maintained by site personnel
- Uses customer preferred proximity Sensor 2 or 3 wire PNP/NPN
Trailing Arm Tachometer
- Convenient location near weigh frame
- Run-clean scraper assembly
- Easily Maintained by site personnel
- Uses customer preferred proximity Sensor 2 or 3 wire PNP/NPN
- Encoder type available
Damped Wheel Tachometer
- Counterbalanced for constant wheel loading
- Rotary Damper keeps wheel in contact
- Developed for difficult applications with high belt stretch
- Run-clean wheel design
- High frequency Encoder type for optimum performance
Precision Pre-calibrated Tachometer Variant
The Precision Pre-Calibrated tachometer features a wide, large diameter, low inertia wheel made from 316 stainless steel with adjustable spring tension designed to give optimum contact to the underside of the carry belt
PFS4 Belt Weigher Products
PFS4-2
- Fully suspended four load cell weigh frame design series
- Very robust weighframe typically 20-30+ year life
- 2, 3,4, 5 or 6 idler weigher
- Dimensions and idler spacing to suit site
- Large range of steel and load cell sizes to suit client site specidic requirements
- NMI, NTEP, OIML trade certified
- True accuracy range in real operation determined by application engineering
PFS4-4
- Fully suspended four load cell weigh frame design series
- Very robust weighframe typically 20-30+ year life
- 2, 3,4, 5 or 6 idler weigher
- Dimensions and idler spacing to suit site
- Large range of steel and load cell sizes to suit client site specidic requirements
- NMI, NTEP, OIML trade certified
- True accuracy range in real operation determined by application engineering
PFS4-4-CSRR
- Variant of PFS4 for special applications to achieve true high accuracy range in real operation
- Used when standard design by any manufacturer cannot reliably meet specified accuracy
- Capable of +/-0.1% accuracy in real operation
- Independantly verified
- Unique to CST
PFS4-4-NI
(Non Intrusive)
- Non-Intrusive version does not require the removal of cross bracing
- Fully suspended four load cell weigh frame design series
- Very robust weighframe typically 20-30+ year life
- 2, 3,4, 5 or 6 idler weigher
- Dimensions and idler spacing to suit site
- Large range of steel and load cell sizes to suit client site specidic requirements
- NMI, NTEP, OIML trade certified
- True accuracy range in real operation determined by application engineering
- Unique to CST
