Belt Weighers Overview



 Belt Weigher Model: HPFS4

A high precision fully suspended 4 point conveyor weighing system

  1. 4 load cells (with stainless pod covers)
  2. 6 - 8 idler weighlength
  3. NMI trade approved class 0.5
  4. High accuracy application up to 0.1%
  5. Non-Intrusive
  6. Shear beam load cell used in tension

 Belt Weigher Model: PFS4

A precision fully suspended 4 point conveyor weighing system

  1. 4 load cells (with stainless pod covers)
  2. 2 - 8 idler weighlength
  3. NMI trade approved class 0.5
  4. High accuracy application up to 0.25%

 Belt Weigher Model: PCS2

A precision centrally suspended 2 point conveyor weighing system

  1. 2 load cells (with stainless pod covers)
  2. 2 - 4 idler weighlength
  3. NMI trade approved class 1
  4. Accuracy application up to 0.5%

 Belt Weigher Model: PCX2

A precision centrally cross supported 2 point conveyor weighing system

  1. 2 load cells (with stainless pod covers)
  2. 1 - 2 idler weighlength
  3. NMI trade approved class 1
  4. Accuracy application up to 0.5%
  5. Suited for tight and complex applications

 Belt Weigher Model: PCS1

A precision centrally suspended single point conveyor weighing system

  1. 1 load cell (with stainless pod cover)
  2. 1 idler weighlength
  3. NMI trade approved class 2
  4. Accuracy application up to 1.0%
